Introduction
The whole system is plug-and-play, easy
to transport, install and maintain.lt consists of battery module,PCS, STS
(optional), MPPT (optional), control system, fire control system, and
temperature control system, monitoring system one-stop integration, through the
synergy of the system components to
achieve.
lt adopts AC coupled micro grid
structure, PCS, load, grid, and access to AC bus, and the corresponding control
strategy is developed according to the actual case to ensure the safety of
power supply.
The battery cluster consists of 21
modules connected in series, and the whole battery system is controlled by BCM
to monitor the cluster voltage and current in real time.
The battery
module consists of 10200 AhLiFePO4cells; distributed BMM control system with
functions of collecting battery voltage, collecting battery temperature, and
battery equalization to ensure the module works
Effectively and safely
PRODUCT
FEATURES
⚫Adopt automotive grade high
performance lithium iron phosphate (LFP) battery, safe and reliable.
⚫Intelligent temperature control to
ensure optimal temperature environment and lower system power consumption.
⚫Real-time data backup.
⚫Automatic fire fighting system
with good safety.
⚫Support parallel and off-grid
switching function.
⚫One button start, automatic
operation, support multiple parallel connection.
⚫Protection class IP55, suitable
for outdoor use.
⚫Four layers of safety protection
design, safe and reliable.
⚫Support remote viewing service.
|
◎Model
|
30Kw/100kWh
|
60Kw/147.8kWh
|
|
◎Battery parameters
|
|
Cell
Type
|
LFP-220Ah
|
LFP-220Ah
|
|
Module Model
|
IP10S
|
IP10S
|
|
Battery
Cluster Configuration
|
1P150S（15Module）
|
IP210(21Module)
|
|
System
Configuration
|
1*1P150S
|
1*IP210S
|
|
Battery Capacity（BOL）
|
100kWh
|
147.84kWh
|
|
Battery voltage range
|
420V-540V
|
588V-756V
|
|
◎AC on-grid parameters
|
|
Grid Type
|
3P4W
|
3P4W
|
|
Rated
charge/discharge power
|
30KW
|
60kW
|
|
Rated
grid voltage
|
AC400V
|
AC400V
|
|
Rated
grid frequency
|
50Hz
|
60Hz
|
|
Frequency
range
|
±5Hz
|
±5Hz
|
|
Rated current
|
43A
|
86A
|
|
Power
Factor
|
1（Ahead）~1（Lag）
|
1（Ahead）~1（Lag）
|
|
Output
Harmonics
|
≤3%
|
≤3%
|
|
◎AC off-grid parameters
|
|
Rated output power
|
30KW
|
60KW
|
|
Rated
output voltage
|
AC400V
|
AC400V
|
|
Rated
output frequency
|
50Hz
|
50Hz
|
|
Rated
current
|
43A
|
86A
|
|
Voltage
accuracy
|
1%
|
1%
|
|
Frequency
accuracy
|
0.2Hz
|
0.2Hz
|
|
◎General parameters
|
|
Dimension
(W*D*H)
|
1861*1835*1267mm
|
1861*1835*1267mm
|
|
Weight
|
1950kg
|
2200kg
|
|
IP
Protection Rating
|
IP55（Battery room）IP53(Electrical room)
|
IP55（Battery room）IP53(Electrical room)
|
|
Seismic
Intensity Rating
|
8（IEC60980）
|
8（IEC60980）
|
|
Anti-corrosion
grade
|
C3
|
C3
|
|
Operating
temperature【1】
|
-20℃～50℃
|
-20℃～50℃
|
|
Relative
Humidity
|
0-95%（Non-condensing）
|
0-95%（Non-condensing）
|
|
Working
altitude【2】
|
＜2000m
|
＜2000m
|
|
Cooling
method
|
Battery section: air conditioning
Power section: forced air cooling
|
Battery section: air conditioning
Power section: forced air cooling
|
|
Noise
|
≤75dB
|
≤75dB
|
|
System
efficiency
|
≥88%
|
≥88%
|
|
Cycle
life
|
5 years or more than 2000 times
|
5 years or more than 2000 times
|
|
Fire
Fighting System
|
Automatic fire extinguishing
|
Automatic fire extinguishing
|
|
Fire
extinguishing media
|
FM200
|
FM200
|
|
Communication
Interface
|
Ethernet
|
Ethernet
|
|
Communication
protocols
|
Modbus TCP/IP
|
Modbus TCP/IP
|
|
Warranty
|
3 years
|
3 years
|
|
◎Photovoltaic
side parameters (optional)
|
|
Maximum
input module power
|
30KW
|
60KW
|
|
MPPT
Voltage Range
|
200V-420V
|
200V-580V
|
|
Number
of MPPT paths
|
1
|
1
|
|
Number
of PV input channels
|
1
|
1
|
|
Maximum
input current
|
100A
|
100A
|
◎ Notes：
【1】The system will be derated when the ambient temperature exceeds 45℃.
【2】The system will be derated when the altitude is between 2000 and 3000m.
◎Standard Certification：
【1】System: GB_T 36558, IEC 62933
【2】PCS: GB_T 34120
TYPICAL SYSTEM LAYOUTS
◎ Notes： STS are available as options.
On
and off-grid (seamless switching)
